Camden CM-9800 7 Surface Mount LED Illuminated Capacitive Push Exit Switch

CM-9800 Series surface mount capacitive touch switches, with LED illumination, are vandal and weather resistant with IP 66 rating. The units feature a cast metal design and an adjustable 0 to 60 second relay timer. The CM-9800 has an external input, so that the switch illumination may be activated by either the switch status or the door (locked) status.

The large surface area of the capacitive switch is easy to activate, with only a light touch, and the large LED light illumination enables the switch to be highly visible in low light conditions.

CM-9800 series illuminated capacitive touch switches are designed for use where high visibility and vandal resistance is required. They are ideal for use as ‘Request to Exit’ switches in access control applications, as well as for activation of automatic door operators, where permitted by building code. CM-9800 series switches may also be used for other door control or equipment switching applications.

Features:

• Capacitive light touch technology. No moving parts
• ADA and ROHS Compliant
• Weather and vandal resistant. IP 66 rated
• Large LED Light Ring, RED, GREEN ORANGE NONE
• Switch status or door status illumination (External input)
• Hold Open relay timer, selectable 0 to 60 seconds
• Heavy duty Form C relay, rated 2 Amps
• Tamper alarm
• 12 24V, AC DC

• Specifications:

  Input Voltage:		12 24V, AC DC
  Current Draw:		Max.65mA
  Relay Output:		2 A @ 24 VDC 120 VAC
  Set Relay Time:		0.5 to 60 Seconds or toggle (ON OFF)
  LED Illumination:		Red, Green, Orange
  LED Control:		Yes, by DIP switch
  Tamper:		Yes
  Back Light On Off:		Yes, by DIP switch
  Buzzer On Off:		Yes, by DIP switch
  Operating Temperature:		-4°F to 122°F (-20°C to 50°C)
  Housing:		Die-cast aluminum alloy
  Protection:		IP66
  Dimensions:		4-9 16 H x 3-3 8 W x 13 16 D (116mm x 86mm x 21mm)
