Uniview Tec IPB5180X IR Turret Camera 1.68mm 5MP True Day Night WDR Panoramic 180° Lens

Key Features:

• Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
• Exceptional Video Quality with 5MP, (2880 x 1620 Resolution)
• Super-Efficient H.265 Video Compression for Drastically Reduced Bandwidth and Storage Requirements
• Powerful, Smart IR LED Lights for 0Lux Night Time Operation up to 66 Feet
• Panoramic 1.68mm, 180° lens; ONVIF Profile S Compliant
• TRUE Day Night and WDR functionality for all Lighting Conditions
• Triple Video Streams, Defog, Dewarping, Backlight Compensation and 3D DNR
• Intelligent perimeter protection such as cross line and intrusion, with smart intrusion prevention technology for significantly reduced false alarms when focusing on humans and motor vehicles
• PoE & 12VDC Power Options and Optional Mounts Available
• Built-in Micro-SD Card Slot enables local storage up to 256GB
• 3-way Axis, IP67 Weather Resistant Housing
• Supported by uniview tec Guard Station Software and Guard Viewer Mobile App s for iPhone and Android Devices

• Specifications:

  Camera
  Sensor		1 2.7 , progressive scan , 5 megapixel, CMOS
  Lens		Panoramic 1.68mm @ F2.0
  Angle of View (H x V)		180° x 180°
  Shutter		Auto Manual, 1 6 ~ 1 100000 s
  Minimum Illumination		Color: 0.01 Lux (F2.0, AGC ON); 0 Lux with IR
  Day Night		IR-cut filter with auto switch (ICR)
  Digital noise reduction		2D 3D DNR
  Smart IR LED Control; Range		Auto Manual On Off; Up to 20m (66ft)
  WDR		120dB
  Video Compression		Ultra 265, H.265, H.264, MJPEG
  H.264 code profile		Baseline profile, Main Profile, High Profile
  Maximum Frame Rate Stream		Main: 5MP (2880 x 1620) @ 30fps Sub: 1080P (1920 x 1080) @ 30fps Third Stream: D1 (720 x 576) @ 30fps
  HLC, BLC, Defog, Flip, Dewarping		Supported
  OSD, Privacy Mask, Motion Detection & ROI		Up to 8 areas
  Network
  Protocols		IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS
  Compatible Integration		ONVIF (Profile S, G, T), API
  Network		RJ45, 10M 100M Base-TX Ethernet
  Intelligent Perimeter Prevention		Line Crossing, Intrusion & Leave Area detection w Smart Intrusion Prevention Technology for False Alarm Prevention
  Local & Network Storage		Micro-SD, up to 256GB; ANR
  General
  Power		12VDC + – 25%; PoE (IEEE802.3 af); Power consumption: Max 5.5W
  Dimensions (L x W x H) & Weight		198 x 71 x 71mm (7.8 x 2.8 x 2.8”); .42kg (0.93lb)
  Audio & Compression		Built-in Mic; G.711A & G.711U Compression
  Alarm I O		1 1
  Operating Temperature & Humidity		-30°C ~ +60°C (-22°F ~ 140°F); Humidity: 10%~ 95% RH (non-condensing)
  Conformity Certifications		IP67, CE, FCC
